– – – – – -Structure- – – – – –

Tube Main Frame Construction for ultimate strength and durability.
2” x 4” Steel Tube Main Frame 24” o/c
1” x 1-¼” Steel Tube Sidewalls 16” O/C
1” x 1-¼” Semi Crowned Steel Tube Roof 24” O.C.
Automotive Undercoating
One Piece Aluminum Roof: provides a leak free smooth exterior finish. No seams= no water = no maintenance

– – – – – -Running Gear- – – – – –

(2) 3500# Axles
EZ-Lube Hubs
(2) ST205/75R15 Radial Tires: Radial tires run cooler which leads to a longer life span especially when the tires are used at full capacity.

– – – – – -Exterior Features- – – – – –

0.30 Aluminum Exterior
Aluminum Fenders
32”w Side Door
24” Stoneguard Protection: Protects the front aluminum panels from rock chips or any other debris that could damage your front aluminum panels.
LED Tail Lights & LED Clearance Lights
176” Overall Length

– – – – – -Towing Features- – – – – –

2” Coupler
Safety Chains
2000# Front Wind Jack w/Sand Pad
4 Pin Plug

– – – – – -Interior Features- – – – – –

10’ + 24” Vnose Interior Length
(1) Dome Light w/wall switch
¾” High Performance Floor: Moisture resistant throughout the panel, not just the surface. Performs better in moisture resistance testing than plywood.
3/8” High Performance  Walls
Sidewall Vents
